Asrock H510 PRO BTC+ Mining Board, Intel H510, 1200, 6x PCIe 3.0 x16, 1 Mining Port, 3x 24-pin ATX, HDMI, M.2

Name: Asrock H510 PRO BTC+ Mining Board, Intel H510, 1200, 6x PCIe 3.0 x16, 1 Mining Port, 3x 24-pin ATX, HDMI, M.2
Brand: Asrock H510 PRO BTC+ Mining Board, Intel H510, 1200, 6x PCIe 3.0 x16, 1 Mining Port, 3x 24-pin ATX, HDMI, M.2
SKU: SPTECH-ASMBH510PROBTC
Price: 187.99 GBP
Availability: OutOfStock

Be the first to review this product

£187.99 incl. VAT + Free Shipping

Out of stock

SKU

SPTECH-ASMBH510PROBTC

Asrock H510 PRO BTC+ Mining Board, Intel H510, 1200, 6x PCIe 3.0 x16, 1 Mining Port, 3x 24-pin ATX, HDMI, M.2

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

Motherboard Type: Mining
Socket: Intel 1200
Chipset: Intel H510
#Hide#DDR Type: DDR4
CPU Support: Click here for CPU support
RAM Slots: 1 x DIMM
RAM Speeds: 3200 / 2933 / 2800 / 2666 / 2400 / 2133 MHz
Maximum Memory: 32GB
Graphics: Integrated Graphics*

*Graphics specifications may vary between CPU types
Graphics Ports: 1 x HDMI
PCI/PCI Express: 6 x PCIe 3.0 x16 Slots (PCIe1 at x16 / PCIe2~6 at x1)
1 x Mining Port (M_Port1 at x1)*

*Support USB Type Riser kit
Storage: 1 x SATA III
1 x M.2 (2260/2280/22110) - SATA
LAN: GB LAN
USB Ports Supported: "2 x USB 3.2 Gen1 (at back)
4 x USB 2.0 (2 at back, 2 at mid-board)"
Back Panel I/O Ports: 1 x PS/2 Mouse/Keyboard
1 x HDMI
2 x USB 2.0
2 x USB 3.2 Gen1
1 x RJ-45 LAN
Internal I/O Connectors: 1 x System Panel
1 x SPI TPM
1 x Power LED and Speaker
1 x CPU Fan
8 x Chassis Fan
3 x 24 pin ATX
1 x 8 pin 12V
4 x 4 pin PCIe
1 x USB 2.0
1 x Power Button
1 x Reset Button
Accessories: "Quick Installation Guide, Support CD
1 x SATA Data Cable
1 x Screw for M.2 Socket"
Additional Features: See Overview
Package Type: Retail
Package Weight: 1.8500 kg
Warranty: 2 Years Replacement Warranty
#Hide#M.2 Slot(s): Yes (M.2)
#Hide#No. LAN Ports: 1 x LAN
#Hide#Max LAN Speed: GB LAN

More Information

More Information
Specifications	This motherboard is specifically designed for mining, the revolutionary digital crypto-currency that may be used anywhere in the world. The abundant onboard PCIe slots guarantee fast Crypto mining, while the additional power connectors provide advanced system stability while mining. Supports 10th Gen Intel® Core™ Processors and 11th Gen Intel® Core™ Processors Supports DDR4 3200MHz Graphics Output: HDMI 6 PCIe 3.0 x16, 1 Mining Port (M_Port1 at x1) 1 SATA3, 1 M.2 (SATA3) 2 Rear USB 3.1 Gen1 Type-A 4 USB 2.0 Type-A (2 Rear, 2 Front) Intel® Gigabit LAN 2 Extra 24-pin ATX Power Connector Onboard Power On / Reset Button Fully Independent Power Rail M.2 For SSD M.2 socket supports 2260/2280/22110 SATA3 mode M.2 SSD for up to 6Gb/s. Smart PCIe State Detection This motherboard has included a smart way to show the status of every graphics card. While the system is booting, the Power-On, Self-Test (POST) screen will show the status of the graphics cards that were installed on the motherboard. USB Type PCIe x1 Mining Ports Onboard USB Type PCIe x1 Mining Ports for Setting Up Even More Graphics Cards. PCI-E Steel Slots The advanced PCI-E Steel Slots packed with solid cover that prevent any signal interference with graphics cards. It also ensures the heavy graphics cards to be well-installed in the PCI-E slots safely. Riser Kit Free Install graphics cards directly on the motherboard without using riser kits to ensure ultimate stability. Intel® LAN Intel® LAN provides the best throughput performance, lower CPU utilization, enhanced stability and is able to deliver ultimate network experience to users! Sapphire Black PCB Pure black PCB appearance. The new Sapphire Black PCB represents rock-solid quality and gives the motherboard a more mysterious touch. High Density Glass Fabric PCB High Density Glass Fabric PCB design that reduces the gaps between the PCB layers to protect the motherboard against electrical shorts caused by humidity. Power On / Reset Button Power On & Off system with onboard button is a must for open frame mining. Digi Power Unlike traditional motherboards that use analog power, this motherboard uses a next generation digital PWM (Pulse-Width Modulation) design, which provides CPU Vcore voltage more efficiently and smoothly, so that the stability and lifespan of the motherboard is greatly enhanced. Full Spike Protection Some sensitive digital components on the motherboard are vulnerable to power surges, the excessive current may cause your system to malfunction immediately. ASRock Full Spike Protection includes various technologies to prevent your motherboard’s components from being damaged by these unexpected voltage spikes. Live Update & APP Shop ASRock Live Update & APP Shop is designed for your convenience. We provide various apps and support software for users to download. You can also easily optimize your system and keep your motherboard up to date with ASRock Live Update & APP Shop.
