Asrock Rack EPYCD8-2T Server Board, AMD SP3 LGA4094, ATX, 8 Channel DDR4, Dual 10G LAN, IPMI, OCuLink Support, mini SAS, M.2
£440.99
incl. VAT
+ Free Shipping
Out of stock
SKU
SPTECH-ARMBEPYCD82T
Asrock Rack EPYCD8-2T Server Board, AMD SP3 LGA4094, ATX, 8 Channel DDR4, Dual 10G LAN, IPMI, OCuLink Support, mini SAS, M.2
- Motherboard Type: Server / Workstation
- Form Factor: ATX
- Socket: AMD SP3 (LGA4094)
- #Hide#DDR Type: DDR4
- CPU Support: Click here for CPU support
- RAM Technology: DDR4 (Eight Channel)
- RAM Slots: 8 x DIMM
- RAM Speeds: RDIMM: 2666/2400MHz
LRDIMM: 2666/2400MHz - Maximum Memory: 128GB
- Graphics: ASPEED AST2500
DDR4 128Mb - Graphics Ports: 1 x VGA
- Multi-GPU Support: -
- PCI/PCI Express: PCIe 3.0 x 16:
- PCIE1: Gen3 x16 link
- PCIE3: Gen3 x16 link
- PCIE5: Gen3 x16 link
- PCIE7: Gen3 x16 link
PCIe 3.0 x 8:
- PCIE2: Gen3 x8 link
- PCIE4: Gen3 x8 link
- PCIE6: Gen3 x8 link - Storage: 9 x SATA III (from 2x mini SAS & 1x SATA DOM)
2 x M.2 (2230/2242/2260/2280) - SATA & PCIe - Wireless: -
- LAN: Dual 10G LAN & Dedicated IPMI LAN port
- Audio: -
- USB Ports Supported: "4 x USB 3.1 Gen 1 (2 at back, 2 at mid-board)
2 x USB 2.0 (at mid-board)" - Back Panel I/O Ports: 1 x VGA
2 x USB 3.1 Gen1
2+1 RJ45 Gigabit LAN
1 x Serial Port
1 x UID Button/UID LED - Internal I/O Connectors: 1 x SATA DOM
2 x M.2
1 x Front LED
1 x Auxiliary Panel
1 x TR1
1 x TPM
1 x IPMB
7 Fans x 6-pin (1CPU/4Front/2Rear)
1 x USB 3.1 (Gen1)
1 x USB 2.0
1 x Speaker
1 x BMC_SMB - .: 1 x Clear CMOS
1 x PSU SMB
4 x ATX Power (24-pin + 8-pin + 4-pin + 6-pin) - Additional Features: See Overview
- Package Type: Retail
- Package Weight: 1.7000 kg
- Warranty: 3 Years
- #Hide#M.2 Slot(s): Yes (M.2)
- #Hide#RGB Lighting: No
- #Hide#No. LAN Ports: 2 x LAN
- #Hide#Max LAN Speed: 10GB LAN
| Specifications |
|
|---|
