Asrock X570 STEEL LEGEND, AMD X570, AM4, ATX, 4 DDR4, HDMI, DP, XFire, RGB Lighting, PCIe4, Rock-Solid Durability, M.2
£201.99
incl. VAT
+ Free Shipping
Out of stock
SKU
SPTECH-ASMBX570STEELLEGEND
Asrock X570 STEEL LEGEND, AMD X570, AM4, ATX, 4 DDR4, HDMI, DP, XFire, RGB Lighting, PCIe4, Rock-Solid Durability, M.2
- Motherboard Type: Desktop
- Form Factor: ATX
- Socket: AMD AM4
- Chipset: AMD X570
- #Hide#DDR Type: DDR4
- CPU Support: Click here for CPU support
- RAM Technology: DDR4 (Dual Channel)
- RAM Slots: 4 x DIMM
- RAM Speeds: AMD Ryzen series CPUs (Matisse)
DDR4 4666+(OC)/4400(OC)/
4300(OC)/4266(OC)/4200(OC)/4133(OC)/3466(OC)/3200/2933/2667/2400/ 2133
AMD Ryzen series CPUs (Pinnacle Ridge)
DDR4 3600+(OC)/3466(OC)/3200(OC)/2933/2667/2400/2133
AMD Ryzen series CPUs (Picasso)
DDR4 3466+(OC)/3200(OC)/2933/2667/2400/2133 - Maximum Memory: 128GB
- Graphics: Integrated AMD Radeon Vega Series Graphics in Ryzen Series APU
- Graphics Ports: 1 x HDMI
1 x DisplayPort 1.2 - Multi-GPU Support: Supports AMD Quad CrossFireX
- PCI/PCI Express: AMD Ryzen series CPUs (Matisse)
2 x PCI Express 4.0 x16
AMD Ryzen series CPUs (Pinnacle Ridge)
2 x PCI Express 3.0 x16
AMD Ryzen series CPUs (Picasso)
2 x PCI Express 3.0 x16
3 x PCI Express 4.0 x1 - PCI: -
- Storage: 8 x SATA III
1 x Hyper M.2 ( 2230/2242/2260/2280) - PCIe
1 x Hyper M.2 (2230/2242/2260/2280/22110) SATA & PCIe - RAID: "RAID 0, 1, 10"
- Wireless: -
- LAN: GB LAN
- Audio: 7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec)
- USB Ports Supported: "2 x USB 3.2 Gen2 Type-A & C (at back)
8 x USB 3.2 Gen1 (6 at back, 2 at mid-board)
4 x USB 2.0 (at mid-board)" - Back Panel I/O Ports: 2 x Antenna
1 x PS/2 Mouse/Keyboard
1 x HDMI
1 x DisplayPort 1.2
1 x Optical SPDIF Out
1 x USB 3.2 Gen2 Type-A
1 x USB 3.2 Gen2 Type-C
6 x USB 3.2 Gen1
1 x RJ-45 LAN
HD Audio Jacks - Internal I/O Connectors: 1 x SPI TPM
1 x Power LED and Speaker
1 x AMD Fan LED
1 x RGB LED
1 x Addressable LED
1 x CPU Fan
1 x CPU/Water Pump Fan
4 x Chassis/Water Pump Fan
1 x 24 pin ATX
1 x 8 pin 12V
1 x 4 pin 12V
1 x Front Audio - .: 1 x AMD LED Fan USB
1 x Thunderbolt AIC
2 x USB 2.0
2 x USB 3.2 Gen1 - Accessories: "Quick Installation Guide, Support CD
4 x SATA Data Cables
3 x Screws for M.2 Sockets
2 x Standoffs for M.2 Sockets" - Additional Features: See Overview
- Package Type: Retail
- Package Weight: 2.2000 kg
- Warranty: 3 Year Replacement Warranty
- #Hide#M.2 Slot(s): Yes (M.2)
- #Hide#RGB Lighting: Yes (RGB)
- #Hide#No. LAN Ports: 1 x LAN
- #Hide#Max LAN Speed: GB LAN
| Specifications |
Rule your own Lighting Way - Polychrome Sync Enjoy stunning performance and superior aesthetics with your unique rig! The built-in ARGB LEDs or the connected devices can be synchronized across the Polychrome Sync-certiHyper M.2 socket to support next certified accessories. Dual Hyper M.2 Hyper M.2 socket to support next certified accessories. generation PCIe Gen4 x4 M.2 SSDs. A massive full coverage M.2 Heatsink to dissipate heat efficiently and ensure your high speed M.2 SSD always working at its best. Flexible Integrated I/O Shield Reserve more tolerance space and allow IO shield is adjustable when installing, thus fitting chassis perfectly without any mechanical issue. Steel Slot with New Gen PCI Express 4.0 The next generation PCI Express 4.0 is capable of performing twice the speed compared to previous 3rd generation. ASRock’s exclusive Steel Slot with extra anchor points are revolutionary added to ensure signal stability and also making sure heavy graphics cards to be well-installed in the PCI-E slot safely. 10 Power Phase Design Featuring sturdy components and completely smooth power delivery to the CPU. It offers enhanced performance with the lowest temperature for advanced gamers as well. |
|---|
